Bently Nevada 3300 XL 330701-00-24-90-12-00 11 mm Proximity Probe

Bently Nevada 3300 XL 11mm Proximity Probe – Reliable Machine Monitoring

Quick Overview

• Model: 3300 XL 11mm (330701-00-24-90-12-00)
• Cable: 9m FluidLoc, triaxial 75 Ω
• Thread: 1/2-20 UNF, stainless steel case
• Temp Range: -51°C to +177°C
• Warranty: 12 months

Key Features

• Strong Build: AISI 304 stainless steel case, PPS tip for tough conditions.
• FluidLoc Cable: Resists oils and chemicals (option 12 in suffix).
• Easy Setup: Standard 1/2-20 UNF thread, finger-tight connector.
• Precise Readings: 8.5 ± 1.1 ohms resistance (9m cable).

Full Model Suffix Breakdown

• 330701-00-24-90-12-00
• 00: No unthreaded section (0.0 in).
• 24: Case length = 2.4 in.
• 90: Cable length = 9.0 meters.
• 12: FluidLoc cable + ClickLoc connector.
• 00: No agency approvals.

Technical Specs

Thread Torque: Max 45.2 N•m (use 15.2 N•m for safety).

Bend Radius: 25.4 mm (min).

Weight: 0.17 kg.

Seal Material: Viton O-ring (avoid below -34°C).

Connector Torque: 0.565 N•m max (finger tight).

5 Expert FAQs

Can this probe handle high-pressure environments?
No. It seals pressure but isn’t tested. Contact us for custom tests.

Why choose FluidLoc cable (suffix “12”)?
It resists oils and chemicals better than standard cables.

What’s the max cable length?
9 meters (29.5 ft). Shorter options (1m, 5m) available.

Is the probe tip replaceable?
No. The PPS tip is built into the stainless steel case.

How to avoid seal damage?
Keep temps above -34°C during storage/use.
