Bently Nevada 3300 XL 8 mm Probe Without Armor | 330140-08-10-12-05

Bently Nevada 3300 XL 8mm Probe (330140-08-10-12-05)

🔍 Product Overview

Model 330140-08-10-12-05 is a high-performance 8mm non-armored proximity probe designed for industrial monitoring. Built with AISI 303/304 stainless steel casing and PPS plastic probe tip, it features FluidLoc cable technology to prevent fluid ingress. Includes Miniature Coaxial ClickLoc connector (12 code) and meets CSA/ATEX/IECEx approvals (05 suffix).

🚀 Key Features

• 330 N (75 lbf) pull strength via patented CableLoc design
• 7.59 Ω ±0.50 DC resistance at 1.0m length
• 7.87 V/mm ±5% incremental scale factor (1m system)
• ±0.025mm linearity deviation (5m system)
• 323 g/m (11.4 oz) weight per meter
• 1-year manufacturer warranty against defects

🌡️ Enhanced Durability

Operates in -52°C to +218°C (ETR version) with Viton® O-ring pressure seal. Maintains <3% ASF change in 93% humidity (IEC 68-2-3 tested). The 8mm diameter provides 300% thicker coil encapsulation vs standard probes.

🔧 Technical Specifications

• Overall Case Length: 0.8″ (08 suffix)
• Cable Length: 1.0m/3.3ft (10 suffix)
• Pressure Rating: Differential pressure sealed
• TipLoc® Molding: Patented tip-body bond
• ETR Option: Up to +260°C cable tolerance

📜 Certifications & Warranty

Includes Certificate of Origin (COO) on request. All 3300 XL 8mm probes come with 12-month quality assurance. Meets IECEx, ATEX, and CSA standards for hazardous environments.
