Bently Nevada 3300 XL 8 mm Probe Without Armor | 330140-08-50-01-00

Bently Nevada 3300 XL 8 mm Probe (Model 330140-08-50-01-00)

⚡ Premium Durability & Performance

3300 XL 8 mm probes deliver industrial-grade robustness with 8.73Ω ±0.5 DC resistance and 330N (75 lbf) CableLoc pull strength. The patented TipLoc molding enhances tip-body bonding, while the stainless steel case (AISI 303/304) withstands extreme conditions. ✔ 1-year warranty included.

📏 Precision Configuration Options

• Total Length: 5.0 meters (16.4 ft) optimized for 5m Proximitor sensors
• Connector: Miniature coaxial ClickLoc with protector (01 option)
• Case Length: 0.8 inches (08 designation)
• FluidLoc Option: Prevents oil/liquid leakage (add-on available)

🔬 Technical Excellence

• Scale Factor: 7.87 V/mm ±5% (5m system)
• Linear Range: 0.25mm increments over 80 mils

• Deviation: ±0.025mm (5m system)
• Humidity Resistance: <3% ASF change @93% RH for 56 days (IEC 68-2-3)

🌡️ Extreme Environment Ready

• Standard Probe: -52°C to +177°C (-62°F to +350°F)
• Extended Range: Tip: +218°C, Cable: +260°C
• Pressure Warning: Avoid <-34°C (-30°F) to prevent seal failure
• Weight: 323g/m (11.4 oz/ft)

🔧 Enhanced Design Features

The 330140-08-50-01-00 model features:
• PPS Plastic Tip with 8mm encapsulation
• Viton® O-ring pressure seal (pre-installed)
• ETR Compatibility: Maintains 7.87 V/mm ±6.5% accuracy in extended temps
• Certificate of Origin (COO) available upon request

🚨 Critical Alert

Probes ship unpressurized – pressure testing required post-installation. Avoid sharp bends beyond 25mm radius to protect CableLoc integrity.
