Bently Nevada | 3300 XL 8 mm Proximity Probe 330101-00-12-05-02-CN

🔩 Core Specifications

The Bently Nevada 330101-00-12-05-02-CN vibration probe features a compact 1.2″ case for tight spaces. Built with 8mm rugged tip and 3/8-24 UNF thread. Includes 1-year protection plan. USA-made.

📐 Model Configuration

• Full ID: 330101-00-12-05-02-CN
• No smooth section: 0.0″ (Code 00)
• Case: 1.2″ short-body (Code 12)
• Cable: 1.6 ft flexible (Code 05)
• Connector: ClickLoc snap-on (Code 02)

🛡️ Built for Tough Jobs

• TipLock Shield: 75 lb pull resistance
• Upgrade Option: FluidLoc anti-leak cable
• Materials: PPS plastic tip + 303 SST body
• Weight: 11.4 oz per meter

📈 Performance Metrics

• 7.45Ω ±0.5 at 1.6 ft cable
• Detection Range: 0.01″-0.09″ (0.25-2.3mm)
• Temp Range: -62°F to +350°F (-52°C to +177°C)
• Cable Limit: Handles +500°F (+260°C)

📜 Compliance & Support

• Moisture Test: <3% error after 8 weeks
• Wiring: 16-24 AWG (max 1000ft run)
• Precision: ±5% accuracy 32-113°F
• Docs: Free COO available
