Bently Nevada | 3300 XL 8 mm Proximity Probe 330101-00-20-05-01-05

Product Highlights

The Bently Nevada 330101-00-20-05-01-05 is an 8mm vibration probe with a 2.0-inch stainless steel case and connector protector. Made in USA. Includes 1-year warranty.

Key Features

• Model: 3300 XL 8mm Probe
• Thread: 3/8-24 UNF
• Case Length: 2.0 in (Code 20)
• Cable: 0.5m (1.6 ft) with protector (Code 01)
• Certified: CSA/ATEX/IECEx (Code 05)

Simple Specs for 330101-00-20-05-01-05

• Temp Range: -62°F to +350°F (-52°C to +177°C)
• Cable Strength: 75 lb pull tested
• Accuracy: ±0.025mm (±1 mil)
• Humidity: Works in 93% RH

Why This Probe?

Built to last in tough conditions:
– 2x thicker case (2.0 in vs 0.8 in standard)
– ClickLoc+Protector prevents connector damage
– PPS tip resists chemicals and heat
– Viton® seal blocks oil leaks

Quick Facts

• 7.45Ω resistance (±0.50)
• 69.9 pF/m cable rating
• 323 g/m (11.4 oz) weight
• Works up to 1,000 ft cable length

Safety & Support

• Explosion-proof certified (ATEX/IECEx)
• Optional COO certificate available
• Pressure seal testing on request
• Stable in wet environments (56-day test)
