Bently Nevada | 3300 XL 8 mm Proximity Probe 330101-00-20-05-01-CN

Key Features

The Bently Nevada 330101-00-20-05-01-CN is an industrial-grade 3300 XL 8 mm vibration probe with a 3/8-24 UNF thread and connector protector (01 option). Built for reliability, it features a compact 2.0-inch case, country-specific approvals (CN), and a 1-year warranty. Made in the USA.

Technical Specs for 330101-00-20-05-01-CN

• Case Length: 2.0 in (20 option)
• Cable Length: 0.5 m / 1.6 ft (05 option)
• Pull Strength: 330 N (75 lbf) with CableLoc tech
• Resistance: 7.45 Ω ±0.50 at 0.5 m
• Temp Range: -62°F to +500°F (cable)
• Weight: 323 g/m (11.4 oz)

Certifications

Approved for country-specific safety standards (CN). Tested in 93% humidity for 56 days with under 3% performance shift.

Durability Highlights

• Connector Protector: Shields coaxial ClickLoc connector from damage
• 8 mm PPS Tip: 30% thicker than standard probes
• Stainless Steel Case: AISI 303/304 resists corrosion

Installation Guide

Supports 1,000 ft cables using 16-24 AWG shielded wiring. Set radial gap to -9 Vdc (50 mils). Keep above -30°F to avoid seal damage.

Warranty & Options

1-year warranty included. Add FluidLoc oil-blocking cable or request pressure seal testing (contact factory). Free COO available.
