Bently Nevada – 3300 XL 8mm – 330130-040-01-00 – Extension Cable

Bently Nevada 330130-040-01-00 Armored Cable

Heavy-Duty Sensor Connection

Model 330130-040-01-00 features 4-meter armored construction for industrial environments. Made in USA with 1-year full warranty. Optional COO available.

Key Specifications

• 🛡️ Armor Weight: 0.618kg | Standard: 0.204kg
• ⚡ Voltage Range: -17.5V to -26V DC
• 📏 Length: 4.0m (11.5ft) ±2% tolerance
• 🔌 Connectors: Gold ClickLoc (500+ mating cycles)

Performance Data

• Core Resistance: 0.88Ω ±0.13Ω
• Shield Resistance: 0.26Ω ±0.05Ω
• 50Ω output with 69.9pF/m capacitance
• 2mm linear range (0.25-2.3mm gap)

Durability Features

• 330N cable pull strength (75 lbs force)
• Viton® O-ring pressure seals
• 3% max performance variation in 93% humidity
• 2000m altitude operation capability

Package Contents

• Armored extension cable
• Silicone tape (non-oil applications)
• Installation reference sheet

Critical Notes

• ⚠️ Not suitable for turbine oil exposure
• ⚠️ Maintain voltage above -23.5V DC
• ⚠️ 305m maximum field wiring distance
