Bently Nevada – 3300 XL 8mm – 330130-045-03-05 – Extension Cable

Bently Nevada 330130 Extension Cable

Key Features

Model 330130-045-03-05 is a 4.5-meter armored cable for factory sensor systems. It has CSA/ATEX/IECEx safety approvals and comes with connector protectors. Made in USA. 1-year warranty included.

Technical Details

• Length: 4.5m (14.8ft)
• Weight: 0.618kg (armored version)
• Wire Resistance: 0.99Ω (core) / 0.30Ω (shield)
• Max Voltage: -26VDC
• Temperature: -40°C to +125°C

Strong Build

Has CableLoc tech that handles 330N (75lbs) pulling force. Armored design protects against crushing. Optional FluidLoc seal stops oil leaks (35 bar pressure tested).

Easy Installation

Works with 3300 XL 8mm probes. Use 16-24 AWG wires for field connections. Includes silicone tape for quick fixes. Keep 1.27mm gap from target for best results.

Reliable Performance

Works in wet air (93% humidity) for 56 days with <3% change. Supports cables up to 305 meters. Made with Viton® O-rings for tight seals.

What’s Included

Armored extension cable, connector protectors, silicone tape. Certificate of Origin (COO) available on request.

Warranty & Support

1-year protection against factory defects. Contact us for technical help with your 330130-045-03-05 cable setup.
