Bently Nevada 3300 XL 8mm 330130-070-12-05 Extension Cable

Bently Nevada 330130-070-12-05 – Safety-Rated FluidLoc Solution

Hazardous-area ready cable with triple certifications and built-in leak protection. Perfect for explosive environments. Made in USA.

Model Breakdown

• ◆ Product Base: 330130
• ◆ 070 → 7.0 meter length (22.9 ft)
• ◆ 12 → FluidLoc + Connector Protector
• ◆ 05 → CSA + ATEX + IECEx Certified

Critical Specifications

• Safety Approvals: CSA, ATEX, IECEx
• Cable Weight: 0.238 kg (34g/m)
• Electrical Values:
  • Core: 1.54Ω ± 0.23Ω
  • Jacket: 0.46Ω ± 0.09Ω
  • Output: 50Ω
• Environmental Limits:
  • Temp: 18°C to 27°C
  • Altitude: 2000m max
  • Humidity: 93% for 56 days
• Power Range: -17.5Vdc to -26Vdc
• Connection Strength: 330N (75 lbf)

Installation Tips

• Probe + cable = total system length
• Max distance: 305 meters
• Use shielded triad cable (16-24 AWG)
• Required in oil environments

System Compatibility

• For 3300 XL 8mm systems only
• Calibrated for AISI 4140 steel
• Gap setting: 1.27mm (50 mils)

Package Contents

• 1x 7.0m FluidLoc cable
• Pre-installed connector protector
• Silicone tape (backup)

Service & Delivery

• 12-month performance guarantee
• Global express: FedEx, UPS, DHL

Expert Questions

• Q: What zones is this certified for?
  A: Approved for Zone 1 hazardous areas
• Q: Temperature limits for certifications?
  A: Meets -40°C to +85°C for ATEX/IECEx
• Q: Chemical resistance of seals?
  A: Viton® O-ring resists oils and fuels
• Q: Can I use in offshore platforms?
  A: Yes, certified for marine applications
• Q: Replacement connector availability?
  A: Available through authorized partners
