Bently Nevada Extension Cable: Precision Connectivity for Industrial Sensors
Product Description
Premium 7.5-meter armored extension cable for 3300 XL vibration monitoring systems. Features patented CableLoc™ technology with 330N pull strength and TipLoc™ molding for superior durability. Includes silicone tape for connector protection. Made in USA.
Technical Specifications
Brand: Bently Nevada
Full Model: 330130-075–00–00
075 = 7.5m cable (24.6 ft)
00 = Standard armored cable
00 = Approvals not required
Weight: 0.772 kg (Armored)
DC Resistance (RCORE): 1.65Ω ±0.25Ω
DC Resistance (RJACKET): 0.49Ω ±0.10Ω
Capacitance: 69.9 pF/m
Operating Voltage: -17.5Vdc to -26Vdc
Output Resistance: 50Ω
Linear Range: 0.25-2.3mm (10-90 mils)
Key Features
- Patented CableLoc™ design (330N pull strength)
- Optional FluidLoc™ oil-leak prevention
- Includes silicone tape for connection protection
- Humidity resistant (93% for 56 days)
- Armored construction for harsh environments
Installation Guide
Max field wiring: 305m (1000 ft) with 3-conductor shielded triad cable. Gap probe at 1.27mm (50 mils) from AISI 4140 steel target. Do NOT use silicone tape in turbine oil applications. Optimal performance between 18°C-27°C at ≤2000m altitude.
Compatibility
Designed for 3300 XL 8mm Proximitor Sensors and probes. For accurate readings, use with AISI 4140 steel targets only. System calibration required for other materials.
Approvals
No special certifications required (as per model suffix 00). Complies with IEC humidity standards.
Package Contents
- 1x Extension cable (7.5m)
- Silicone tape set
- Installation documentation
Warranty & Shipping
12-month manufacturer warranty. Ships worldwide via FedEx, UPS, DHL.
