Bently Nevada 330106-05-30-50-12-CN Reverse Mount Probe
Product Overview
This reverse mount probe is part of the Bently Nevada 3300 XL 8 mm series. It is used for checking vibration in industrial machines. This model is strong, heat-resistant, and easy to install. It is made in the USA and used in many harsh conditions.
Key Technical Specs
- Thread: M10 x 1
- Max Thread Depth: 15 mm
- Probe Length: 5.0 meters
- Tip Material: Polyphenylene sulfide (PPS)
- Case Material: Stainless steel (AISI 303 or 304)
- Connector Type: Miniature ClickLoc, FluidLoc cable
- Probe Weight: 323 g/m
- Resistance: 8.73 ± 0.50 ohms
- Cable Type: 75Ω triaxial, FEP or PFA insulated
- Optional Armor: Stainless steel with FEP jacket
- Connector Material: Gold-plated brass or beryllium copper
Temperature Limits
- Standard: -52°C to +177°C
- High Temp Tip: up to +218°C
- High Temp Cable: up to +260°C
- Do not use below: -34°C
Environmental Performance
- Pressure Seal: Viton O-ring (not tested at factory)
- Humidity: Less than 3% signal change at 93% humidity for 56 days
- Tensile Strength: 330 N (probe case), 270 N (probe lead)
Mounting Guide
- Mount in threaded M10 x 1 hole
- Ensure thread depth does not exceed 15 mm
- Use in clean and dry areas
Compatibility
- Compatible with 330105 Proximitor sensors
- Works with Bently Nevada extension cables
Packaging Contents
- 1x Reverse Mount Probe 330106-05-30-50-12-CN
- 1x Probe tip protector
- 1x Quick start installation sheet
Warranty and Delivery
- 12-month warranty included
- Ships via FedEx, UPS, or DHL
- Secure and durable packaging
Complete Model Tree
- 330106 – Series type
- 05 – Tip option
- 30 – Cable type
- 50 – Length: 5.0 meters
- 12 – Connector: ClickLoc with FluidLoc
- CN – Country-specific certification
