Bently Nevada | 3300 XL 8mm Reverse Mount Probe 330105-02-12-05-12-05

Essential Details

The Bently Nevada 330105-02-12-05-12-05 is a heavy-duty 8mm reverse-mount probe with 3/8-24 UNF threads. Made in the USA, it meets CSA/ATEX/IECEx safety standards (Approval Code: 05).

Key Specs for 330105-02-12-05-12-05

• Length: 0.5 meters (±0.50mm)
• Resistance: 7.45Ω ±0.50Ω
• Max Pull Force: 330N (75 lbs) at probe / 270N (60 lbs) at cable
• Weight: 323g per meter (11.4 oz)

Built Tough

• Tip Material: PPS plastic (chemical-proof)
• Body: Stainless steel 303/304
• Seal: Viton® O-ring (pressure-safe design)
• Cable Options: Standard (FEP) or High-Heat (PFA)

Smart Choices

FluidLoc Cable (Option 12):
Most installations don’t need this due to probe sleeves. Check your setup first.

Performance Limits

• Normal Use: -62°F to +350°F (-52°C to +177°C)
• High-Heat Mode: Up to +500°F (+260°C) cable rating
• Cold Warning: Fails below -30°F (-34°C)

Quality Guarantee

• 1-Year Warranty: Defect coverage
• Certified: Passes 93% humidity tests (56 days)

Quick Facts

• Cable Sizes: 0.5m to 9m options
• Connectors: Gold-coated parts
• Armor Option: Stainless steel + FEP jacket

Document Download Here:3300 XL 8 mm Proximity Transducer System Datasheet
