Bently Nevada | 3300 XL 8mm Reverse Mount Probe 330105-02-12-15-12-05

Core Specifications

330105-02-12-15-12-05 | 3300 XL 8mm Reverse Mount Probes | 1.5m length (4.9ft) | 7.73Ω ±0.50 DC resistance

Suffix Decoding for 330105-02-12-15-12-05

• -15: 1.5m cable (4.9ft) | • -12: ClickLoc coaxial connector
• -05: CSA/ATEX/IECEx certifications | Threads: 3/8-24 UNF (14.3mm max engagement)

Physical Properties

• • 323g/m (11.4oz/ft) weight | • Armor: Optional SST with FEP jacket
• • Cable: FEP/PFA insulation | • 75Ω triaxial impedance
• • Tensile: 330N case-to-cable | 270N connector points

Environmental Resilience

• • -52°C to +177°C standard range
• • Extended: +218°C tip / +260°C cable
• • Humidity: <3% ASF change @93% RH/56 days
• • Pressure: Viton® O-ring seal (untested)

Compliance & Support

• ATEX/IECEx/CSA certified
• 1-Year Warranty | Material: PPS tip + SST303/304 case

Configuration Notes

• • FluidLoc cable not recommended for standard installations
• • Avoid <-34°C exposure to prevent seal failure
• • Custom pressure testing available on request

Document Download Here:3300 XL 8 mm Proximity Transducer System Datasheet
