Bently Nevada | 330101-00-53-05-02-00 3300 XL 8 mm Proximity Probe

🛠️ Precision Machinery Monitor

The Bently Nevada 330101-00-53-05-02-00 combines a 5.3″ case with 8mm rugged tip for mid-range industrial monitoring. Features 3/8-24 UNF threading and 1-year full coverage. Made in USA.

🔩 Build Specifications

• Full Code: 330101-00-53-05-02-00
• Case: 5.3″ optimized length (Code 53)
• Thread: Full-surface 3/8-24 UNF
• Cable: 1.6 ft standard (Code 05)
• Connector: ClickLoc snap-fit (Code 02)

💥 Impact-Resistant Design

• TipLock Core: 75 lb pull-proof bonding
• Upgrade Path: Add FluidLoc leak shield
• Construction: PPS tip + 303 SST body
• Density: 11.4 oz/m (323 g/m)

📐 Performance Essentials

• 7.45Ω ±0.5 @ 1.6ft cable
• Detection: 0.01″-0.09″ (0.25-2.3mm)
• Temp Range: -62°F to +350°F (-52°C to +177°C)
• Cable Safety: +500°F (+260°C) rated

✅ Compliance & Support

• Seal: Viton® O-ring (request pressure test)
• Humidity: 93% RH endurance (56 days)
• Wiring: 16-24 AWG (max 1000ft)
• Docs: Free COO available
