Bently Nevada | 330101-00-90-05-02-CN 3300 XL 8 mm Proximity Probe

Key Features

The Bently Nevada 330101-00-90-05-02-CN is a heavy-duty 3300 XL 8 mm Probe for industrial vibration monitoring. Features a 3/8-24 UNF thread, country-specific approvals (CN), and a 1-year warranty. Made in the USA with PPS plastic tip and stainless steel case.

Technical Specs for 330101-00-90-05-02-CN

• Case Length: 9.0 in (90 option)
• Cable Length: 0.5 m / 1.6 ft (05 option)
• Cable Grip: 330 N (75 lbf) pull strength
• Resistance: 7.45 Ω ±0.50 (0.5 m system)
• Temp Range: -62°F to +500°F (cable/connector)
• Weight: 323 g/m (11.4 oz)

Certifications

Meets country-specific safety standards (CN). Works in 93% humidity for 56 days with less than 3% performance change.

Durability Upgrades

• 9-inch Case: Extra-long stainless steel design for tough installations
• TipLoc Technology: 25% stronger tip-to-body bond
• FluidLoc Option: Blocks oil leaks (add when ordering)

Setup & Use

Works with 1,000 ft cables using 16-24 AWG shielded wires. Keep above -30°F to protect seals. Includes ClickLoc connector (02 option) for quick installation.

Warranty

1-year coverage against defects. Add Certificate of Origin (COO) for export needs.
