Bently Nevada | 330106-05-30-15-02-00 3300 XL 8mm Proximity Probe

Bently Nevada 330106-05-30-15-02-00 Reverse Mount Probe

Product Overview

The Bently Nevada 330106-05-30-15-02-00 is a 3300 XL 8 mm Reverse Mount Proximity Probe. Designed for industrial machinery monitoring, it delivers high reliability in harsh environments. It uses M10x1 mounting threads and includes a Miniature ClickLoc coaxial connector.

Key Technical Specifications

• Probe Length: 1.5 meters (4.9 feet)
• Resistance: 7.73 ± 0.50 ohms
• Tip Material: Polyphenylene sulfide (PPS)
• Case Material: Stainless Steel AISI 303 or 304
• Connector: Miniature ClickLoc coaxial (Option 02)
• Thread Size: M10x1
• Thread Engagement: Max 15 mm
• Operating Temperature: -52°C to +177°C (Standard)
• Extended Temp Range: -52°C to +218°C (Tip), -51°C to +260°C (Cable)
• Humidity Tolerance: ≤3% variation in ASF at 93% humidity (56 days)

Cable and Connector Details

• Standard Cable: 75Ω triaxial, FEP insulated
• Extended Temp Cable: 75Ω triaxial, PFA insulated
• Optional Armor: SST flexible armor with FEP jacket
• Connector Material: Gold-plated brass or beryllium copper

Full Model Breakdown

• 330106-05-30-15-02-00
  • 05: Probe type
  • 30: Total cable length (3.0 m, but model specific is 1.5 m)
  • 15: Probe length = 1.5 meters
  • 02: Miniature ClickLoc coaxial connector
  • 00: No agency approval

Installation Guide

• Mount the probe using M10x1 threaded hole
• Ensure maximum thread engagement is 15 mm
• Do not expose probe tip to temperatures below -34°C

Compatibility

• Works with 3300 XL extension cables
• Compatible with Bently Nevada Proximitor sensors
• Best for reverse mount installations in tight machinery spaces

Shipping

• Ships via FedEx, UPS, or DHL
• Same-day dispatch available for in-stock units
