Bently Nevada 330172-00-12-10-02-CN 5mm Proximity Probe

Bently Nevada 330172-00-12-10-02-CN – 5mm Proximity Probe with Armor

Complete Model Breakdown

• 330172 – Base model
• 00 – 0″ unthreaded length
• 12 – 1.2″ case length
• 10 – 1.0 meter cable
• 02 – ClickLoc connector
• CN – Country approvals

Key Features

• 5mm vibration probe with armor
• 1/4-28 UNF threaded case
• Made in USA
• PPS probe tip material
• 304 stainless steel body

Technical Specifications

• Power: -17.5V to -26V DC
• Current: 12mA max
• Output: 50Ω resistance
• Probe resistance: 7.59Ω ±0.50
• Temperature range: -35°C to +177°C
• Cable: 1.0m FEP insulated
• Thread engagement: 0.375″ max
• Weight: 0.323kg

Installation Notes

• Use #3 or larger tap drill
• Recommended torque: 5.1 N·m
• Max torque: 7.3 N·m
• Min cable bend: 25.4mm

5 Professional FAQs

• What target material works best? AISI 4140 steel recommended
• Can I use this in cold environments? Not below -34°C to avoid seal damage
• What’s the cable insulation? Fluoroethylene propylene (FEP)
• How much pull force does it withstand? 222N (50lbf) on all connections
• What connector type is used? Gold-plated ClickLoc miniature coaxial

Shipping & Warranty

• Fast shipping: FedEx, UPS, DHL
• 12 month coverage on defects
• No repair or misuse coverage
