Bently Nevada 330500 Velomitor Piezo-Velocity Sensor

Description

Bently Nevada 330500-00-04 is a rugged multi-certified piezo-velocity sensor designed for critical machinery monitoring. Built with 316L stainless steel, it combines CSA and ATEX approvals for global hazardous area compliance. Features hermetic sealing and stable performance across -55°C to 121°C extremes.

Technical Data

• Brand: Bently Nevada
• Model: 330500-00–04
  • -00: No adapter mounting thread
  • -04: CSA + ATEX dual certification
• Range: 1270 mm/s peak | Precision: ±5% sensitivity
• Output: 3.94mV/mm/s | Noise: 0.004 mm/s rms
• Frequency: 4.5 Hz–5 kHz (±3dB) | Resonance: >12 kHz

Installation

• Torque: 24-40 in-lb (32-46 kg cm)
• Max cable: 305m (part# 02173006)
• Polarity: Case motion toward connector → Pin A+

Certificated

• FCC Part 15 | EMC 2014/30/EU | RoHS
• CSA/US/C + ATEX Ex ia/IIC T4
• DNV Marine Standards
