Bently Nevada 330702-00-26-50-02-00 | 3300 XL 11 mm Proximity Probe
The Bently Nevada 330702-00-26-50-02-00 proximity probe is built for stable vibration and position measurement.
It fits harsh industrial sites and long cable routing needs.
Basic Information
- Brand: Bently Nevada
- Model: 330702-00-26-50-02-00
- Series: 3300 XL 11 mm
- Origin: Made in U.S.A
- Warranty: 12 Months
Main Selling Points
- Designed for 5.0 meter systems only
- Stable output over long distance
- Strong sealing for oil and gas use
- Low drift over temperature changes
- High mechanical strength with armor
Core Technical Data
- Probe Diameter: 11 mm
- Total Cable Length: 5.0 m (16.4 ft)
- Thread Type: 1/2-20 UNF
- DC Resistance: 7.2 Ω ±0.8
- Probe Tip Material: PPS
- Probe Case Material: AISI 304 SST
- Cable Impedance: 75 Ω triaxial
- Minimum Bend Radius: 25.4 mm
- Shipping Weight: 0.17 kg
Mechanical & Environmental Limits
- Operating Temperature: -52°C to +177°C
- Maximum Case Torque: 45.2 N·m
- Recommended Case Torque: 15.2 N·m
- Connector Torque: Finger tight (max 0.565 N·m)
- Seal Type: Viton O-ring
Model Code Tree
- 330702
- 00 → Unthreaded length: 0.0 in
- 26 → Case length: 2.6 in
- 50 → Cable length: 5.0 meters
- 02 → ClickLoc connector, standard cable
- 00 → No agency approval required
Logistics
- Shipping via FedEx
- Shipping via UPS
- Shipping via DHL
Professional FAQ
- Why must this probe be used with a 5 meter Proximitor?
- Cable resistance and signal balance are tuned for 5 m systems only.
- Is this probe suitable for high vibration machines?
- Yes. The armored cable and steel case improve vibration resistance.
- What happens if torque is too high?
- Over-torque may damage threads or sealing performance.
- Can it work in cold start conditions?
- Avoid installation below -34°C to protect the pressure seal.
- How do I choose cable length?
- Always match probe length with the Proximitor sensor length.
