Bently Nevada 330708-00-24-90-02-00 3300 XL 11 mm Proximity Probe

Bently Nevada 330708-00-24-90-02-00 Proximity Probe – 3300 XL 11mm with 9m Cable

Long-range vibration monitoring solution featuring compact 2.4″ housing and extended 9m (29.5ft) cable. Made in USA with 12-month warranty.

Key Advantages

• Industry-longest 9m cable for maximum installation flexibility
• Space-saving 2.4″ design fits tight machinery spaces
• Stainless steel heavy-duty construction
• ClickLoc quick-connect system
• Extreme -51°C to +177°C temperature range

Model Configuration Breakdown

330708-00-24-90-02-00
│   │  │  │  │  └─► 00: Standard version (no approvals)
│   │  │  │  └────► 02: ClickLoc connector (standard cable)
│   │  │  └───────► 90: 9.0 meter extended cable
│   │  └──────────► 24: 2.4" compact case length
│   └─────────────► 00: 0" unthreaded section
└─────────────────► 330708: Base 11mm probe model

Technical Specifications

• Cable Resistance: 8.5Ω ±1.1Ω (9m version)
• Standard Thread: 5/8-18 UNF (M14/M16 options available)
• Installation Torque: 400 in-lb max (133 in-lb recommended)
• Cable Type: 75Ω triaxial with FEP insulation
• Minimum Bend Radius: 25.4mm (1.0″)
• Shipping Weight: 0.17 kg (0.37 lbs)

Compatibility Notes

• Designed specifically for use with 9m Proximitor Sensors
• Not compatible with 1m/5m sensor versions
• Maintain above -34°C to prevent seal damage

Shipping & Support

• Fast worldwide delivery via FedEx/UPS/DHL
• Complete 12-month warranty

Expert Questions Answered

• Q: What’s the advantage of 9m cable?
  A: Allows sensor placement far from monitoring equipment
• Q: Is the standard cable oil-resistant?
  A: Standard version is moisture-resistant (FluidLoc version for oils)
• Q: Why higher resistance than shorter cables?
  A: Cable length increases nominal resistance to 8.5Ω
• Q: What’s the thread engagement depth?
  A: 0.938″ for 5/8-18 UNF thread
• Q: Can I get different connector types?
  A: Other connector options available as special order

Documentation Download

• • Extended Cable Installation Guide
  • 9m System Compatibility Sheet
