Bently Nevada Armored Extension Cable – Heavy Duty Protection
Complete Part Number Breakdown
- 330730: 3300 XL 11mm Cable Series
- 040: 4.0 Meter Length
- 01: Armored Cable Option
- 05: Multiple Agency Approvals
Core Specifications
- Armor Type: AISI 302 SST with FEP jacket
- Weight: 0.56kg (Armored)
- Tensile Strength: 330N at probe case
- Capacitance: 69.9 pF/m typical
- Resistance: Core 1.0Ω ±0.25 / Shield 0.3Ω ±0.1
- Temp Range: -52°C to +177°C
Armored Cable Benefits
- Stainless steel armor for crush protection
- 3X higher impact resistance vs standard
- Extra abrasion resistance in harsh plants
- Maintains flexibility despite armor
Installation Guide
- Max Bend Radius: 8x cable diameter
- Pull Force Limit: 270N at connectors
- System Length: Up to 9 meters total
- Pre-drilled safety wire holes included
FAQ
Q: How does armor protect the cable?
A: Stainless steel braid prevents crushing and cuts
Q: Can I use in explosive environments?
A: Yes – meets ATEX/IECEx standards
Q: Difference between standard and armored weight?
A: Armored version weighs 0.56kg vs 0.18kg standard
Q: Minimum bend radius for armored version?
A: Minimum 50mm bend radius
Q: Can I add FluidLoc to armored cable?
A: Yes – order special combination option
