Bently Nevada 330907-05-30-50-02-CN 3300 NSv Reverse Mount Probe

Bently Nevada 330907-05-30-50-02-CN Reverse Mount Probe

Product Summary

The Bently Nevada 330907-05-30-50-02-CN is a 3300 NSv series reverse mount probe with M10x1 threads and a 5.0 meter cable. It features a miniature coaxial ClickLoc connector with a standard cable and is suited for use in small machines, especially compressors and chemically harsh environments.

Model Breakdown

• 330907: NSv reverse mount probe series
• 05: Unthreaded tip length
• 30: Probe case length
• 50: Total probe length = 5.0 meters
• 02: Miniature ClickLoc connector with standard cable
• CN: Country-specific approval

Technical Parameters

• Measuring Range: 0.25 to 1.75 mm (10 to 70 mils)
• Signal Output: -1 V to -13 V DC
• Accuracy: Maintains linearity within 1.5 mm (60 mils)
• Gap Setting: Recommended at 1.0 mm (40 mils)
• DC Resistance: 4.2 ± 0.5 ohms (1.0 m)

Temperature Ratings

• Operating: -52°C to +177°C
• Storage: -52°C to +177°C
• Note: Avoid use below -34°C for long time to prevent seal damage

Mechanical Data

• Tip Material: PPS (Polyphenylene sulfide)
• Case Material: AISI 304 stainless steel
• Thread Size: M10x1, 15 mm engagement
• Max Torque: 22.6 N·m (200 in·lb)
• Recommended Torque: 7.5 N·m (66 in·lb)
• Weight: 14–150 g
