Bently Nevada 330907-05-30-70-02-CN 3300 NSv Reverse Mount Probe

Bently Nevada 330907-05-30-70-02-CN Reverse Mount Probe

Product Summary

This Bently Nevada 3300 NSv reverse mount probe is made for machines in harsh conditions. It gives high signal clarity even in chemical-heavy or hot places. It is mainly used on process compressors and rotating equipment.

Model Code Breakdown

• 330907: NSv Series Reverse Mount Probe
• 05: Probe tip option
• 30: Case length
• 70: Cable length = 7.0 meters
• 02: Standard ClickLoc coaxial connector
• CN: Country-specific approval

Key Technical Data

• Thread Type: M10x1
• Gap Range: 0.25 to 1.75 mm
• Linear Range: 1.5 mm
• Voltage Output: -1 to -13 VDC
• Recommended Gap: 1.0 mm
• DC Resistance (1m): 4.2 ohms ± 0.5

Installation Info

• Use shielded triad cable for wiring
• Allow 15 mm max thread depth
• Apply 7.5 N·m torque when mounting
• Avoid long exposure below -34°C

Wiring and Compatibility

• Wire Size: 16 to 24 AWG
• Max Distance to Monitor: 305 meters
• System Compatibility: 3300 XL NSv Proximitor Sensor

Package Contents

• 1x 330907-05-30-70-02-CN probe
• 7-meter coaxial cable
• 12-month factory warranty
