Bently Nevada 330907-05-30-70-12-CN 3300 NSv Reverse Mount Probe

Bently Nevada 330907-05-30-70-12-CN Reverse Mount Probe

Overview

This is a Bently Nevada 3300 NSv reverse mount probe. It is made in the USA. The model 330907-05-30-70-12-CN includes a 7.0-meter FluidLoc cable and an M10x1 thread. It is ideal for machines in harsh environments, such as compressors in oil and gas plants.

Model Structure

• 330907: NSv Reverse Mount Series
• 05: Tip length
• 30: Case length
• 70: Cable length = 7.0 meters
• 12: FluidLoc cable with ClickLoc connector
• CN: Country-specific certification

Main Features

• Measurement range: 1.5 mm (60 mils)
• Gap range: 0.25 mm to 1.75 mm (10 to 70 mils)
• Output signal: -1 VDC to -13 VDC
• Recommended gap: 1.0 mm (40 mils)
• Resistance: 4.2 ± 0.5 ohms (for 1 m cable)

Mechanical Details

• Thread type: M10x1
• Thread depth: Max 15 mm
• Max torque: 22.6 N·m
• Best torque: 7.5 N·m
• Case material: 304 stainless steel
• Tip material: PPS plastic
• Weight: 14–150 g

Wiring and Cable

• Wire size: 16–24 AWG
• With ferrules: 18–23 AWG
• Cable type: Shielded triad, 3-wire
• Max cable run: 305 meters to monitor
