Bently Nevada 3500/94M-06-00-01 VGA Display Module

Quick Overview

• Manufacturer: Bently Nevada
• Product Model: 3500/94M-06-00-01
• Product Type: VGA Display Module
• Country of Origin: Made in U.S.A
• Designed for 3500/94M monitoring systems.

Display and Interface Design

• 15-inch industrial LCD display.
• Panel mount design with hardware included.
• Clear VGA analog output.
• Touch interface support.

Electrical Performance

• Maximum power consumption: 4.6 W.
• Front port provides 24 Vdc power output.
• Stable operation under continuous load.

Data and Communication Paths

• High-speed network for system data.
• RS232 port for touch controller input.
• VGA port outputs RGB and sync signals.
• Status LEDs show module and data activity.

Status Indicators

• OK LED confirms normal operation.
• TX/RX LEDs show active communication.

Environmental Operating Limits

• Operating temperature: -20°C to 65°C.
• Storage temperature: -40°C to 85°C.
• Humidity up to 95 percent non-condensing.

Physical Construction

• Monitor Module
  • Dimensions: 241.3 × 24.4 × 241.8 mm.
  • Weight: 0.73 kg.
• I/O Module
  • Dimensions: 241.3 × 24.4 × 99.1 mm.
  • Weight: 0.34 kg.

Display Unit Details

• 15-inch Advantech LCD with LED backlight.
• Resolution optimized for monitoring data.
• Industrial hardened construction.
• Resistive touch interface.
• IP65 front panel protection.

Rack and Mounting Layout

• Monitor module uses one full-height front slot.
• I/O module uses one full-height rear slot.
• KVM extender mounts on top shelf.

Configuration Breakdown

• 3500/94M
  • -06
    • 15-inch display, panel mounted
  • -00
    • No KVM extender cables
  • -01
    • CSA and NRTL Class I Division 2 approval

Compliance and Safety

• FCC Part 15 compliant.
• Meets EMC and electrical safety standards.
• RoHS compliant.

System Requirements

• Requires 3500/22 TDI module.
• Compatible with approved firmware versions.
• Designed for full 3500 system integration.

Why Engineers Choose This Module

• Clear real-time machine data display.
• Reliable operation in harsh environments.
• Panel mount saves rack space.
• Certified for industrial safety use.

Warranty and Shipping

• 12-month warranty included.
• Professional export packaging.
• Shipping via FedEx, UPS, or DHL.

Professional FAQ

• Is this display suitable for continuous operation
• Yes. It is designed for 24-hour industrial use.
• Does the display support touch input
• Yes. It supports resistive touch commands.
• Can this module work without a KVM extender
• Yes. The -00 option does not require KVM cables.
• What should I verify before ordering
• Check firmware versions and TDI availability.
• Is it approved for hazardous locations
• Yes. The -01 option supports Class I Division 2.
