Bently Nevada 330171-00-08-90-01-05: High-Performance 5mm Proximity Probe

Product Description

The Bently Nevada 330171-00-08-90-01-05 is a precision 5mm proximity probe designed for industrial vibration monitoring. Featuring a 1/4-28 UNF threaded stainless steel case and PPS probe tip, it delivers reliable measurements in harsh environments. The 9-meter cable with ClickLoc connector ensures easy installation.

Technical Data

• Brand: Bently Nevada
• Model: 330171-00-08-90-01-05
• Type: 3300 Series 5mm Proximity Probe
• Range: 1.27mm (50 mils) standard gap
• Output: -17.5 to -26 Vdc, 50Ω resistance
• Accuracy: <2mV/V supply sensitivity
• Temperature Range: -35°C to +177°C
• Cable: 9.0m FEP-insulated triaxial
• Thread: 1/4-28 UNF (max engagement 0.375″)

Model Suffix Breakdown

Key Features

• Industrial-grade AISI 304 stainless steel construction
• Chemical-resistant PPS probe tip
• Withstands 222N (50 lbf) tensile load
• Recommended 5.1 N·m (45 in·lb) case torque
• 25.4mm minimum bend radius for cable protection

Installation Guide

For 1/4-28 UNF mounting holes:

• Use #3 or larger tap drill
• Maximum thread engagement: 0.375″
• Maintain 1.27mm (50 mils) probe-to-target gap
• Do not exceed 7.3 N·m (65 in·lb) torque

Compatibility

Works with Bently Nevada 3300 XL monitoring systems. Requires -24Vdc power supply and 10kΩ load. Optimal performance with AISI 4140 steel targets.

Certifications

Complies with multiple international standards (suffix 05 approval option).

Package Includes

• 1x 5mm proximity probe
• Connector protector
• Installation manual

Shipping & Warranty

Shipped via FedEx/UPS/DHL. 12-month warranty against defects.
