Bently Nevada 5mm Proximity Probe | 330171-00-20-10-02-00

Bently Nevada 330171-00-20-10-02-00: 5mm Proximity Probe

Quick Overview

Industrial-grade 5mm vibration probe with a 1.0m cable and 1/4-28 UNF thread. Made in the USA for precision machinery monitoring.

Model Breakdown (330171-00-20-10-02-00)

• 00: 0″ unthreaded length
• 20: 2.0″ case length
• 10: 1.0m cable
• 02: Miniature coaxial ClickLoc connector
• 00: No agency approvals needed

Key Specs

• Thread: 1/4-28 UNF (max 0.375″ engagement)
• Tip Material: PPS (high-temperature plastic)
• Case Material: 304 stainless steel
• Voltage: -17.5 to -26 Vdc, 12 mA max
• Temp Range: -35°C to +177°C
• Cable Bend: Do not bend under 25.4mm (1.0″)
• Weight: 0.323 kg

Installation Notes

• Use a #3 (or larger) tap drill for mounting holes.
• Torque probe case to 5.1 N·m (45 in·lb) (max 7.3 N·m).

5 Expert FAQs

• Q: Can this probe measure non-metallic targets?
  A: No, it requires AISI 4140 steel or similar.
• Q: Is the cable waterproof?
  A: The FEP insulation resists moisture but isn’t submersible.
• Q: What’s the minimum target thickness?
  A: At least 1.5mm (0.06″) for accurate readings.
• Q: Can I cut the cable to shorten it?
  A: No—this voids the warranty.
• Q: How close should the probe be to the target?
  A: Gap at 1.27mm (50 mils) for calibration.

Warranty & Shipping

• 12-month warranty against defects.
• Ships via FedEx, UPS, or DHL.
