Bently Nevada 330172-00-40-10-02-00 Heavy-Duty Vibration Probe
Precision Monitoring for Demanding Applications
- 🛡️ Armored 5mm sensor with 4.0″ stainless steel case
- ⚙️ 1/4-28 UNF threaded industrial connection
- 🔌 1.0 meter cable with secure ClickLoc connector
- 🌡️ Extreme -35°C to +177°C operating range
- ✅ 12-month quality guarantee
Model Number Breakdown
330172-00-40-10-02-00
│
├── 330172 → 5mm armored probe
├── 00 → 0″ unthreaded length
├── 40 → 4.0″ case length
├── 10 → 1.0m cable
├── 02 → ClickLoc connector
└── 00 → No special approvals
│
├── 330172 → 5mm armored probe
├── 00 → 0″ unthreaded length
├── 40 → 4.0″ case length
├── 10 → 1.0m cable
├── 02 → ClickLoc connector
└── 00 → No special approvals
Technical Specifications
- Power: -17.5V to -26V DC @ 12mA max
- Resistance: 7.59Ω ±0.5 (center to outer)
- Thread: 1/4-28 UNF (0.375″ max engagement)
- Weight: 0.323 kg (0.71 lbs)
- Material: AISI 304 stainless steel case
- Cable: 75Ω triaxial FEP insulated
Installation Guide
- 🛠️ Drill with #3 or larger bit
- 🔧 Tighten to 45 in-lb (5.1 N·m)
- 📏 Set 1.27mm (50 mil) gap
- 🔄 Keep 1″ minimum bend radius
- ⚡ Connect to -24V DC system
Professional FAQs
- Why 4″ case length? For deeper mounting applications
- Cable replacement possible? No, integrated design
- Chemical resistance? PPS tip resists most industrial chemicals
- Vibration limits? Withstands 50 lbf tensile force
- Calibration needed? Pre-calibrated for 4140 steel
Package & Support
- 📦 1× Bently Nevada 330172-00-40-10-02-00 probe
- 🛡️ 12-month protection coverage
- ✈️ Worldwide shipping via FedEx/UPS/DHL
