GE Fanuc IC693MDL652 60V DC 16-Channel Discrete Input Module
The IC693MDL652 provides high-voltage DC input capability for Series 90-30 PLC systems. This 16-channel module delivers reliable performance for industrial applications requiring higher voltage signal acquisition.
Technical Specifications
- Brand: GE Fanuc
- Model: IC693MDL652
- Series Compatibility: Series 90-30 Programmable Logic Controllers
- Input Channels: 16 points (single group)
- Input Voltage Range: 0-60V DC
- Trigger Voltage: 34-60V DC
- Input Current: 4.2 mA at rated voltage
- On-State Current: 7.5 mA typical
- On-State Voltage: 15V DC minimum
- Off-State Voltage: 6V DC maximum
- Response Time: 1 ms (on and off)
- Power Consumption: 80 mA @ 5V DC, 125 mA @ 24V DC
- Connector Type: Terminal block with 20 screws
Packaging & Shipping
- Includes one GE Fanuc IC693MDL652 input module
- Professional protective packaging ensures safe delivery
- Worldwide shipping via FedEx, UPS, or DHL available
Frequently Asked Questions
- What voltage range does this module handle? It accepts DC inputs from 0-60V with trigger voltage between 34-60V DC.
- What is the response time? The module features a fast 1ms response time for both on and off transitions.
- Does it include a terminal block? Yes, it comes with an integrated terminal block with 20 screw connections.
- What baseplates are compatible? It works with both 5-slot and 10-slot Series 90-30 baseplates.
