DeltaV VE6049M01 8-Port Expansion Module | Industrial Network Module

VE6049M01 DeltaV 8-Port Expansion Module Overview

The VE6049M01 delivers reliable multi-port expansion for DeltaV distributed control systems.
It supports stable communication across industrial networks using 100-meter twisted pair cabling.
This module ensures efficient data transmission with low power consumption and compact mechanical design.
Engineers use this unit to extend system connectivity without increasing complexity or installation cost.
Oiltech Controls designs this solution for demanding automation environments requiring consistent network performance.

Key Features and Functional Advantages

• This module provides 8 independent communication ports for flexible network expansion.
• It supports 100M TP cable length for extended field connectivity.
• The design maintains low power consumption at 2W for energy-efficient operation.
• It ensures stable performance under 0°C to +50°C operating temperature.
• The compact structure allows easy installation inside RM100 chassis systems.

Technical Specifications

• Brand: DeltaV
• Model: VE6049M01
• Product Type: 8-port Expansion Module
• Power Consumption: 2W
• Heat Dissipation: 7 Btu/h
• Cable Support: Twisted Pair up to 100 meters
• Protection Class: IP20
• Operating Temperature: 0°C to +50°C
• Storage Temperature: -20°C to +85°C
• Humidity Range: 10% to 95% non-condensing
• Dimensions: 138 x 90 x 42 mm
• Weight: 0.21 kg
• Mounting Type: RM100 chassis media module

Mechanical Design and Environmental Resistance

• The enclosure uses a compact footprint for high-density cabinet installations.
• The module operates reliably in industrial environments with controlled humidity conditions.
• It resists electrical interference through stable communication architecture design.
• The IP20 rating protects internal components from solid object intrusion.
• The lightweight structure simplifies handling and reduces installation effort.

Installation Guidelines

• Install the module inside a compatible RM100 chassis following system layout guidelines.
• Ensure proper grounding to maintain signal integrity and reduce electromagnetic interference.
• Use high-quality twisted pair cables for optimal communication performance.
• Avoid installation near high-voltage equipment to minimize signal disruption risks.
• Verify all port connections before powering the system to ensure stable startup.

Packing List

• 1 × DeltaV VE6049M01 8-port expansion module
• 1 × Standard protective packaging
• 1 × Installation instruction sheet
• Shipping via
  FedEx,
  UPS, or
  DHL

Application Scenarios

• This module supports distributed control systems in process automation industries.
• It enables network expansion in oil and gas production control environments.
• Engineers use it in power plants for stable communication between system nodes.
• It fits manufacturing automation systems requiring reliable multi-port connectivity.
• The device integrates seamlessly with DeltaV system architecture.

FAQ

• What systems support this module?
  The module works with DeltaV systems using RM100 chassis configurations.
• How should I select an expansion module?
  You should match port quantity, communication distance, and system compatibility requirements.
• Can this module operate in high humidity environments?
  It operates safely within 10% to 95% non-condensing humidity conditions.
• What cable type ensures best performance?
  Use high-quality twisted pair cables rated for industrial communication networks.
• How do I ensure long-term reliability?
  Maintain proper ventilation, grounding, and avoid electrical noise sources during installation.
