GE Fanuc IC693MDL634 24VDC Positive/Negative Logic Input Module
The IC693MDL634 from GE Intelligent Platforms delivers versatile input capabilities for industrial automation. This 8-point DC input module supports both positive and negative logic operations. It features a wide input voltage range from 0 to 30 volts DC for flexible application use. The module provides excellent isolation between field devices and logic circuits. Individual LED indicators show real-time status for each input point.
Technical Specifications
- Brand: GE Intelligent Platforms/GE Fanuc
- Model: IC693MDL634
- Compatible Series: Series 90-30 PLC Systems
- Input Points: 8 points with single common terminal
- Rated Voltage: 24 VDC
- Input Voltage Range: 0 to 30 VDC
- Isolation Rating: 1500V between field and logic sides
- Typical Input Current: 7 mA at rated voltage
- On-State Voltage: 11.5 to 30 VDC
- Off-State Voltage: 0 to 5 VDC
- On-State Current: 3.2 mA minimum
- Off-State Current: 1.1 mA maximum
- LED Indicators: Individual status lights for each input
Package Contents & Delivery
- One GE Fanuc IC693MDL634 input module
- Comprehensive installation and operation manual
- Industrial-grade protective packaging
- Worldwide shipping via FedEx, UPS, and DHL carriers
Frequently Asked Questions
- What types of logic does this module support?
It supports both positive and negative logic characteristics. - How many input points does the module have?
It features 8 input points with a single common terminal. - What field devices work with this input module?
It works with pushbuttons, limit switches, and other DC sensors. - What is the isolation rating for safety?
It provides 1500V isolation between field and logic sides.
