GE Fanuc IC693MDL648 48VDC Input Module
High-speed 16-point input module for industrial automation. The IC693MDL648 connects your Series 90-30 PLC to various field devices. It features fast response times and supports both positive and negative logic for maximum flexibility.
Technical Specifications
- Brand: GE Fanuc
- Series: Series 90-30
- Model: IC693MDL648
- Module Type: Discrete Input
- Input Points: 16
- Input Voltage Range: 0-60 VDC
- Nominal Voltage: 48 VDC
- Input Current: 4.2 mA
- Trigger Voltage: 34-60 VDC
- Response Time: 1 ms (on and off)
- Power Consumption: 80 mA at 5V DC, 125 mA at 24V DC isolated
- Connector: 20-screw terminal block (included)
- Logic Support: Positive and negative
- Isolation: Optical isolation for signal protection
Package Contents
- 1 x IC693MDL648 Input Module
- 1 x Installation manual
Shipping & Support
- Fast worldwide shipping via FedEx, UPS, DHL
- 12-month product warranty
- Dedicated technical support team
Frequently Asked Questions
- What is the advantage of the fast response time?
The 1ms response time allows for high-speed applications and precise control - Can I use this module with 24V devices?
Yes, the module accepts voltages from 0-60 VDC, including 24V systems - What does trigger voltage mean?
Trigger voltage is the range where the input reliably activates (34-60 VDC) - How many devices can I connect?
The module supports up to 16 individual field devices - Is optical isolation important?
Yes, it protects your PLC from voltage spikes and electrical noise
