GE Fanuc PACSystem RX3i IC694MDL390 AC Input Module

GE Fanuc IC694MDL390 High-Voltage AC Output Module

Core Specifications

• Brand: GE Fanuc
• Series: RX3i PacSystem
• Output Points: 5 isolated channels
• Rated Voltage: 120-240V AC
• Output Current: 2A per point (3A fuse protected)
• Voltage Range: 85-264V AC
• Frequency: 50/60 Hz

Environmental Ratings

• Operating Temp: 0°C to 60°C (32°F to 140°F)
• Storage Temp: -40°C to 85°C (-40°F to 185°F)
• Humidity: 5-95% non-condensing
• Shock Resistance: 15G for 11ms
• Vibration: 10-57 Hz, 0.0524mm peak

Key Features

• Individual commons for each output channel
• RC snubber for transient voltage protection
• LED status indicators for each point
• Red fuse failure (“F”) indicator
• High-voltage identification band
• Compatible with any RX3i I/O slot

Installation Notes

• Requires user-supplied AC power (DC not supported)
• Can be powered from single or multi-phase sources
• Maximum inrush current: 25A per cycle
• Follow IEC60068-2-27/JISC0912 shock standards

Certifications & Compliance

Meets IEC60068-2-6 vibration and JISC0911 standards

Package & Warranty

• GE Fanuc IC694MDL390 module
• Installation documentation
• Warranty: 12 months against defects

Shipping Options

Global delivery via FedEx, UPS or DHL with tracking

Frequently Asked Questions

Q: Can I use DC power with this module?
A: No, AC power supply only (85-264V AC)

Q: What does the red “F” LED indicate?
A: Signals a blown fuse on any output channel

Q: Are the output channels isolated?
A: Yes, each point has separate common

Q: What protection features are included?
A: 3A fuses per output + RC snubber circuits

Q: Can I mix different voltage sources?
A: Yes, outputs can use different AC phases
