GP4106G1D Pro-face HMI 200×80 Dots GP4100 Operator Panel 24VDC

Pro-face Xycom GP4106G1D Monochrome HMI

GP4106G1D is a compact 3.4-inch monochrome operator interface. It delivers reliable control for small machines and legacy systems. The unit uses a 24VDC supply and supports RS-422/485 communication. This HMI belongs to the Pro-face GP4100 series. It offers a green, orange, and red display. The screen resolution is 200 x 80 dots. It is ideal for space-limited panels. The model number is 3910017-03. The global code is PFXGP4106G1D.

Technical Specifications

Key Features and Benefits

• Compact size saves panel space.
• Monochrome display shows clear status colors.
• RS-422/485 supports long-distance communication.
• 24VDC input works with standard industrial power.
• GP-Pro EX software makes programming easy.
• Low power draw reduces heat and energy cost.
• Wide temperature range suits many factory floors.

Installation Guide

Mount the GP4106G1D in a clean, dry panel. Keep the unit away from direct sunlight and heat sources. Use the 24VDC power supply. Make sure the voltage drop is 3 ms or less. Connect the RS-422/485 cable to the correct port. Do not force the connector. Tighten the mounting screws evenly. Leave space for air flow. Follow the original Pro-face manual for panel cutout dimensions.

Commissioning and Maintenance

Use GP-Pro EX to load your project. Check the screen after power-on. The display may fade at high temperatures. This is normal. Clean the screen with a soft, damp cloth. Do not use harsh chemicals. Check cables for wear. Replace worn parts promptly. The unit needs no regular calibration.

Compatibility Notes

The GP4106G1D works with many Pro-face GP4100 series accessories. It communicates with PLCs and controllers via RS-422/485. The GP-Pro EX software supports project transfer and debugging. This HMI is a direct replacement for many obsolete GP4100 units. Check the global code PFXGP4106G1D for exact match.

Certification and Standards

• IEC/EN61131-2 for vibration and shock.
• CE marked where applicable.
• RoHS compliant.

Packaging List

• 1 x GP4106G1D HMI unit.
• 1 x mounting hardware kit.
• 1 x quick start guide.
• Original box and anti-static bag.

Warranty and Shipping

All units come with a 12-month warranty. We ship via FedEx, UPS, and DHL. Tracking is provided for every order. Contact us for express options. Oiltech Controls tests each unit before shipment. We support obsolete control systems.
