MTL4549Y Hazardous Area Signal Converter: Dual-Channel 4-20mA Interface with HART Support

Product Description

The MTL4549Y safely connects 4-20mA signals from controllers in safe areas to equipment in hazardous locations. It drives two current/pressure converters (or loads ≤800Ω) while enabling bi-directional HART communication for valve positioners. Open/short circuits in field wiring trigger automatic current reduction to preset levels for easy fault detection.

Technical Specifications

• Brand/Model: MTL4549Y Series
• Input Signal: 4-20mA floating
• Channels: Two isolated channels
• Load Capacity: 800Ω max (16V @20mA)
• Accuracy: Better than 20μA @20°C
• Temperature Drift: <1.0μA/°C
• HART Bandwidth: 500Hz-10kHz
• Response Time: <100ms to within 200μA
• Fault Detection: Open-circuit (<0.5mA), Short-circuit indicator
• Power Consumption: 70mA @24V DC

Installation Guide

Mount in safe area enclosures. Ensure Zone 0/IIC T4-T6 or Div.1 Group A certification for connected hazardous area devices. Maintain minimum 90Ω load for proper short-circuit detection. Verify wiring integrity using LED power indicator.

Compatibility

Works with all HART-enabled valve positioners and standard 4-20mA field instruments. Accepts signals from controllers with readback functionality. Compatible with any load ≤800Ω including I/P converters.

Certifications

Approved for use in: Zone 0, IIC, T4-T6 hazardous areas and Division 1, Group A locations. Intrinsic safety parameters: Uo=28V, Io=93mA, Po=0.65W.

Package Includes

• 1× MTL4549Y Signal Converter Unit
• Installation Documentation
• Compliance Statements

Warranty & Shipping

12-month manufacturer warranty. Ships worldwide via FedEx, UPS, DHL. Delivery tracking provided for all orders.
