Honeywell MLF-DC04A Industrial Analog Current Output 4 Channels

Overview

The MLF-DC04A from Honeywell provides precise four-channel 4–20 mA analog output for industrial control systems.

Key Features

• Supports DC 4–20 mA and DC 0–20 mA inputs, load ≤510 Ω.
• High resolution: 1/4000 (~5 μA).
• Fast conversion: 1 ms per channel.
• Output limit: ±25 mA.
• Accuracy: ±0.5%.
• Four analog output channels per module.
• Photo-coupler isolation between inputs and PLC power.
• 11-point terminal block for easy wiring.
• Occupies 64 fixed I/O points.
• Power: 110 mA @ 5V, 120 mA @ 24V.
• Weight: 124 g.

Data Formats

• Unsigned: 0–4000 counts
• Signed: -2000–2000 counts
• Precise: 400–2000 counts
• Percent: 0–1000

Installation

• Mount on DIN rail with ventilation.
• Use shielded twisted pair for wiring.
• Set digital input formats via PLC before use.
• Check polarity and loop power before connection.
• Test with controlled loads before live operation.

Packing List

• 1 × MLF-DC04A module.
• 11-point terminal block.
• Quick-start manual.
• Protective foam and carton.
• Shipping via FedEx, UPS, DHL.

Compatibility & Environment

• Works with PLCs supporting 4–20 mA analog input.
• Avoid high humidity or corrosive gas.
• Follow EMC guidelines for wiring.
• Keep away from water and direct spray.

FAQ

• Q: What input ranges does it accept?
• A: DC 4–20 mA and DC 0–20 mA, load ≤510 Ω.
• Q: How fast is conversion?
• A: 1 ms per channel, resolution ~5 μA.
• Q: Is it isolated?
• A: Yes, photo-coupler isolation between inputs and PLC power.
