GE Fanuc IC693CMM301 Genius Communications Module
This communication module enables seamless data exchange between Series 90-30 PLCs and multiple devices. It supports automatic global data sharing across your control system. The IC693CMM301 module simplifies network communications in industrial automation applications.
Product Overview
The IC693CMM301 is a Genius bus communication module for Series 90-30 PLCs. It automatically shares data with up to 7 devices simultaneously. This module creates efficient networks without complex programming.
Key Features
- Automatic Data Sharing: Continuously exchanges 256 bits of global data.
- Multi-Device Support: Connects to 7 Genius bus devices.
- Easy Monitoring: Dual LED indicators show system status.
- Simple Configuration: Set up with software or handheld programmer.
Technical Specifications
- Brand: GE Fanuc
- Model: IC693CMM301
- Series: Series 90-30
- Module Type: Genius Communications Module
- Data Capacity: 256 bits (32 bytes)
- Max Devices: 7 Genius bus devices
- LED Indicators: OK (green), COM (green)
- Voltage: 5V DC (backplane powered)
- Power Consumption: 450 mA @ 5V DC
- Operating Temp: 0°C to 60°C (32°F to 140°F)
- Storage Temp: -25°C to 70°C (-13°F to 158°F)
- Humidity: 5% to 95% non-condensing
- Bus Protocol: Genius Bus
Compatibility
Works with Series 90-30 PLCs and communicates with Series 90-70 PLCs, programming computers, and devices with PCIM cards.
Installation Guide
Insert the module into any available slot in your Series 90-30 rack. Connect Genius bus devices using appropriate cables. Configure using programming software or handheld programmer. Monitor LED status for proper operation.
Package Contents
- 1 x IC693CMM301 Communications Module
- Installation documentation
Shipping & Warranty
Fast worldwide shipping via FedEx, UPS, and DHL. Includes full 12-month warranty coverage.
Frequently Asked Questions
What is global data communication?
It means the module automatically and continuously shares data with multiple devices without special programming.
How many devices can connect to this module?
It can communicate with up to 7 devices on the Genius bus network.
What do the LED indicators show?
The OK LED shows proper operation, and the COM LED shows active bus communications.
How is the module configured?
It must be configured using either a handheld programmer or appropriate programming software.
Does this module require external power?
No, it receives all required power from the Series 90-30 backplane.
