GE Fanuc IC693MDL641 24VDC Input Module
Reliable 16-point input module for industrial automation. The IC693MDL641 connects your Series 90-30 PLC to sensors and switches. It features negative logic operation and clear status indicators for easy monitoring.
Technical Specifications
- Brand: GE Fanuc
- Series: Series 90-30
- Model: IC693MDL641
- Type: Input module
- Input Points: 16
- Logic Type: Negative
- Rated Voltage: 24 VDC
- Input Voltage Range: 0 to 30 VDC
- On-State Voltage: 15-30 VDC
- Off-State Voltage: -30 to 5 VDC
- On-State Current: 4 mA minimum
- Off-State Current: 1.5 mA maximum
- Isolation: 1500V RMS
- Response Time: 7 ms typical
- Power Consumption: 5V from backplane
Installation Guide
- Install in any compatible Series 90-30 rack
- Provide clean, dry environment without corrosive materials
- Connect field devices using proper wiring techniques
- Use status LEDs to verify correct operation
- Ensure power supply matches voltage requirements
Package Contents
- 1 x IC693MDL641 Input Module
- 1 x Installation Guide
Shipping & Support
- Fast worldwide shipping via FedEx, UPS, DHL
- 12-month product warranty included
- Professional technical support available
Frequently Asked Questions
- What does negative logic mean?
Negative logic means the input activates when the signal goes low - Can I use this module with 12V sensors?
Yes, the module works with voltages from 0 to 30 VDC - How do I know if an input is active?
Each input has a dedicated LED indicator that lights when active - What is the isolation rating for?
The 1500V isolation protects the PLC from voltage spikes - Can I mix different voltage sensors?
Yes, as long as all inputs stay within 0-30 VDC range
