GE Fanuc IC693MDL733 24VDC Output Module
Efficient 8-point output module with negative logic operation. The IC693MDL733 provides reliable control for your Series 90-30 PLC system. It features 0.5A per point capacity and is designed for applications requiring negative logic configuration.
Technical Specifications
- Brand: GE Fanuc
- Series: Series 90-30
- Model: IC693MDL733
- Module Type: Discrete Output Module
- Output Points: 8 points
- Rated Voltage: 12-24 VDC
- Output Current: 0.5A per point
- Logic Type: Negative
- Isolation: 1500V between field and logic side
- Power Consumption: 50mA @ 5VDC
- Operating Temperature: 0 to 60°C
- Response Time: 2ms typical
- Voltage Drop: 1V maximum
- Leakage Current: 1mA maximum
Installation Guide
- Install in any Series 90-30 baseplate slot
- Connect user-supplied 12-24VDC power
- Wire devices using negative logic configuration
- Ensure proper grounding and wiring practices
- Verify operation using status LEDs
Package Contents
- 1 x IC693MDL733 Output Module
- 1 x Installation and user manual
Shipping & Support
- Fast worldwide shipping via FedEx, UPS, DHL
- 12-month product warranty included
- Professional technical support available
Frequently Asked Questions
- What is negative logic operation?
Negative logic means the output activates when the control signal is low - What types of devices work with this module?
It controls indicators, relays, small solenoids, and other DC devices - Do I need an external power supply?
Yes, you must provide a separate 12-24VDC power supply - What is the advantage of 1500V isolation?
It protects the PLC from electrical noise and voltage spikes - Can I use this module in high-temperature environments?
Yes, it operates in temperatures from 0 to 60°C
