Powerful 8-Channel Relay Output Module for Industrial Control
The GE Fanuc IC693MDL930 relay output module delivers exceptional flexibility for your automation needs. This versatile IC693MDL930 module features eight fully isolated relay outputs that handle both AC and DC loads with ease. Perfect for controlling motors, solenoids, and indicator lights in various industrial applications.
Technical Specifications
Brand: GE Fanuc
Model: IC693MDL930
Series: Series 90-30
Output Type: 8 Form A Relay Outputs (Normally Open)
Maximum Current: 4A per point (resistive), 2A (pilot duty)
Voltage Range: 5-30VDC / 5-250VAC
Isolation Rating: 1500V between field and logic sides
Response Time: 15ms maximum
Power Consumption: 6mA from 5V bus, 70mA from 24V bus
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Switching Frequency: 20 cycles per minute
Minimum Load: 10mA
Module Width: Single slot
Warranty Coverage
We offer a 12-month warranty against defects. Contact us for support. We ship replacement units quickly via FedEx, UPS, or DHL.
Frequently Asked Questions
Q: Can I mix AC and DC voltages on the same module?
A: Yes! Each output is isolated, so you can use different voltages on each channel.
Q: What is the lifetime expectancy of the relays?
A: The relays typically provide over 100,000 operations at rated load.
Q: Do I need external fuses for protection?
A: While not required, we recommend using external fuses for critical applications.
Q: Can this module control motor starters directly?
A: Yes, it’s specifically designed for motor starters, solenoids, and indicator lights.
Q: What is the maximum total current for the entire module?
A: The module can handle up to 20A total across all outputs for UL installations.
