GE Fanuc IC694MDL330: Powerful 8-Point AC Output Module
Quick Overview
Industrial-grade AC output module for RX3i systems. Controls high-power devices with 240V AC capacity and built-in protection. Perfect for heavy machinery control.
Key Features
- ⚡ 8 protected outputs (2 groups of 4)
- 🔌 120-240V AC operation range
- 🛡️ 5A fuses + RC snubbers on all circuits
- 💡 Green LED status for every point
- 🌡️ Works in tough conditions (0-60°C)
Technical Details
Power Specs
- Output Current: 2A per point
- Voltage Range: 85-264V AC
- Inrush Current: 20A (1 cycle)
- Frequency: 50/60 Hz
Durability
- Temp Range: 0-60°C
- Humidity: 5-95%
- Vibration: 10-500 Hz
- Shock: 15G for 11ms
Protection
- Fuse Rating: 5A per group
- Isolation: 2 separate groups
- Noise Protection: RC snubbers
- Power: External AC required
Installation Notes
- Fits any RX3i I/O slot
- Use AC power only – no DC
- Groups can share power or use different phases
- Check wire size for 2A loads
What’s Included
- IC694MDL330 Output Module
- Installation guide
Support & Delivery
- 12-month quality warranty
- Fast global shipping: FedEx, UPS, DHL
- Complies with JISC0911, IEC60068 standards
Common Questions
Q: Can I use DC power?
A: No – AC power only
Q: How are outputs protected?
A: Each group has 5A fuse + RC snubbers
Q: Maximum load per point?
A: 2A continuous, 20A inrush
Q: Operating temperature limit?
A: 60°C (140°F) maximum
