IC694MDL931 GE Fanuc PACSystem RX3i AC Isolated Input Module

GE Fanuc IC694MDL931 8-Channel Relay Output Module

Industrial-strength relay module for RX3i systems. 8 isolated outputs (4 NC + 4 Form C) with 8A switching capacity. Flexible 5-250V AC/DC operation.

Relay Configuration

• Output Types: 4 Normally Closed + 4 Form C relays
• Isolation: Fully isolated circuits
• Switching Capacity: 8A per point
• Total Module Current: 20A max

Power Flexibility

• Voltage Range: 5-30V DC or 5-250V AC
• Frequency: 50/60 Hz compatible
• Backplane Draw: Only 6mA
• Min Load: 10mA per point

Performance Metrics

• Response Time: 15ms max
• Inrush Handling: 8A per cycle
• Isolation Rating: 250V AC continuous
• Connection: Separate common terminals

Installation Guide

• Requires external AC/DC power supply
• Not hot-swappable
• Fits any RX3i I/O slot
• 32 status LEDs for monitoring

Safety Isolation

• 250V AC continuous isolation
• Field-to-backplane protection
• Output-to-output separation

Package Contents

• IC694MDL931 module
• Installation documentation
• 12-month reliability warranty

Global Shipping

• FedEx Industrial Priority
• UPS Heavy Equipment
• DHL Automation Express
• Worldwide 2-4 day delivery

Key Technical Parameters

• Form C Relays: SPDT configuration
• Contact Rating: 8A resistive load
• Operating Temp: 0°C to 60°C
• Electrical Life: 100,000 cycles
