IC695SPF010 Module | GE PACSystems RX3i – Fiber Optic Scanner

GE Fanuc IC695SPF010 High-Speed Fiber Optic Scanner Module

The IC695SPF010 from GE Fanuc Automation delivers advanced fiber optic connectivity for PACSystems RX3i networks. This high-performance scanner module supports gigabit communication speeds over extended distances. It provides versatile network integration with comprehensive configuration capabilities through Proficy Machine Edition software.

Technical Specifications & Performance Data

• Brand: GE Fanuc Automation
• Model: IC695SPF010
• Module Type: Fiber Optic Scanner Module
• Network Speed: 1000 Mbps (1 Gigabit)
• Fiber Type: Single-mode Fiber (SMF)
• Maximum Distance: 10 kilometers fiber range
• Power Requirements: 3.3V to 5V DC operation
• Port Configuration: 2 RJ-45 + 2 SFP cages
• Current Draw: 1.2A @ 3.3V (no SFP), 1.9A @ 3.3V (2 SFP)
• Maximum Current: 1.1A @ 5V DC

Connectivity & Network Architecture

• The IC695SPF010 supports multiple network topologies including daisy-chain and ring
• It enables star configuration networks for distributed systems
• This module provides line topology support for linear network layouts
• It features versatile media interfaces supporting various connection types
• The module maintains compatibility with Series 90-30 I/O racks
• It integrates seamlessly with RX3i modules and controllers

Configuration & Software Integration

• This scanner module utilizes Proficy Machine Edition software for programming
• It supports SD card functionality for configuration data transfer
• The module enables cable-free data transfers between system components
• Configuration settings reside in software-based files for easy management
• It includes a dedicated USB port for firmware upgrades only
• The USB connection serves temporary maintenance purposes exclusively

Power Management & Electrical Specifications

• Base Power Consumption: 1.2A at 3.3V DC without SFP devices
• Maximum Power Draw: 1.9A at 3.3V DC with two SFP devices installed
• 5V Power Requirement: 1.1A maximum current at 5V DC
• Operating Temperature: 0°C to 60°C standard range
• Storage Temperature: -40°C to 85°C
• LED Status Indicators: Comprehensive module monitoring

Safety & Installation Requirements

• This open-style device requires proper enclosure installation
• It contains accessible hazardous voltages that need protection
• Installation must prevent user contact with live components
• Proper enclosures eliminate potential injury or damage risks
• The module demands standard industrial safety precautions
• It complies with typical industrial control equipment standards

Packaging & Shipping Information

• Your order includes one IC695SPF010 Fiber Optic Scanner Module
• All products ship with comprehensive 12-month warranty coverage
• We provide worldwide shipping via FedEx, UPS, and DHL services
• Standard packaging includes installation guidelines and safety documentation

Comparison with Related RX3i Components

• The IC695SPF010 provides high-speed fiber optic scanning capabilities
• For rackless CPU applications, consider the IC695CPE400 processor
• The IC695CPK330 offers complementary CPU functionality

Professional FAQ Section

• What type of fiber optic cable does this module use?
• It utilizes single-mode fiber optic connections supporting distances up to 10 kilometers.
• How does the power consumption change with SFP devices?
• Power draw increases from 1.2A to 1.9A at 3.3V when two SFP devices are installed.
• What software is required to program this scanner module?
• You need Proficy Machine Edition software for configuration, programming, and monitoring.
• Why does this module require installation in an enclosure?
• As an open-style device, it needs enclosure protection to prevent access to hazardous voltages.
• What network speeds does this scanner module support?
• It supports gigabit communication rates of 1000 Mbps for high-speed data transfer.
