IF2B000014 Honeywell IF2B Fixed RFID Reader 4-Port UHF PoE Reader

IF2B000014 Honeywell IF2B Fixed RFID Reader – High-Performance 4-Port UHF Module

Explore the technical capabilities of this high-performance RFID solution. Please download the full Honeywell IF2B User Manual for detailed wiring diagrams and configuration steps.

Product Overview

• The IF2B000014 is a professional-grade fixed RFID reader for industrial automation.
• This 4-port UHF reader manages high-density tag environments with superior accuracy.
• Built with a die-cast magnesium base to ensure optimal heat dissipation and durability.
• The IP53-rated enclosure protects internal electronics from dust and falling water.
• Engineers prefer the IF2B series for its reliable tag detection and flexible PoE power integration.
• The device meets FIPS 140-2 compliance for high-security enterprise network environments.

Technical Specifications

• Brand: Honeywell
• Model: IF2B000014
• Frequency Range: FCC (902-928 MHz) or ETSI (865-868 MHz) factory configured
• RF Output Power: Configurable from 1 to 30 dBm in 1 dB steps
• Antenna Connections: Four reverse-polarity (RP) TNC ports for mono- or bi-static operation
• Linearity & Tuning: Features antenna fault detection and automatic tuning for peak performance
• Operating Temperature: -25 to 55°C (-13 to 131°F) for extreme industrial climates
• Environmental Tolerance: IP53 sealing with 5% to 95% non-condensing humidity resistance
• Connectivity: 10/100 BaseT Ethernet, RS-232, and USB for local configuration
• Input Power: PoE (802.3at) or 12 VDC (+/-5%) via sealed locking connection
• GPIO Circuits: Four inputs (0-40 VDC) and four outputs (0-48 VDC, 0.25 amp)
• Memory: 96 MB Flash application memory and 64 MB available RAM

Compatibility & Protocol Support

• Supports EPCglobal UHF Class 1 Gen 2 and ISO 18000-6C/6B protocols.
• Compatible with NXP G2X and Impinj Monza 4QT extensions.
• Handles high memory tags from manufacturers like Fujitsu, Tego, and ATA.
• Integrates with EPCglobal LLRP and Honeywell Advanced RFID Extensions (ARX).
• Supports IPv4, IPv6, DHCP, DNS, and NTP network protocols.

Installation & Maintenance

• Mount the unit using the die-cast magnesium base for stable industrial attachment.
• Connect up to four antennas using Honeywell approved cables to maximize sensitivity.
• The Universal Plug and Play (UPnP) support allows for rapid network discovery.
• Monitor system health via LED indicators for RFID service, Power, PoE, and Ethernet.
• The Web Configuration Interface simplifies remote diagnostics and firmware updates.

Diagnostic Capabilities & Security

• Real-time antenna port connection status tracking via hardware LEDs.
• FIPS 140-2 compliance for secure HTTPS and LLRP-secure communication.
• Supports SSL Certificates and RADIUS client for enterprise-level access control.
• Built-in Syslog support enables centralized monitoring of all read events and errors.

Applications & Shipping

• Typical Applications: Warehouse inventory, asset tracking, and automated production lines.
• Packaging List: Honeywell IF2B000014 Reader, Quick Start Guide.
• Warranty: Includes a 12-month standard warranty.
• Shipping Methods: Global delivery via Fedex, UPS, or DHL.
• Inquiries: Contact info@oiltechcontrols.com for technical support.
• Fast Response: Message us on WhatsApp: +86 158 8020 0923.

Frequently Asked Questions

• Does it support PoE? Yes, it is fully 802.3at compliant for power over Ethernet.
• Can I use it outdoors? It has IP53 sealing, suitable for protected industrial environments.
• What is the maximum power? The RF output reaches 30 dBm for long-range detection.
