Product Description
Keyence IV-G500MA is a monochrome sensor head for the IV-G10 amplifier. It belongs to the IV-G Series. This standard model uses automatic focus for fast setup. It captures clear images at distances from 20 mm to 500 mm. The 1/3 inch CMOS sensor delivers 752 x 480 pixels. A white LED supports both pulse lighting and DC lighting. The head connects to the amplifier with a dedicated cable. It has no built-in ports or protocols. All output and communication run through the amplifier. The housing is IP67 rated. It works in temperatures from 0 to +50°C. This model is discontinued. Keyence recommends a replacement. Last verified: 2026-09.
Technical Specifications
| Brand | Keyence |
| Model | IV-G500MA |
| Series | IV-G Series |
| Module Type | Sensor head, standard sensor model |
| Compatible Amplifier | IV-G10 |
| Field of View | Standard, monochrome type |
| Installed Distance | 20 to 500 mm |
| View at 20 mm | 10 (H) x 7.5 (V) mm |
| View at 500 mm | 200 (H) x 150 (V) mm |
| Image Sensor | 1/3 inch monochrome CMOS, 752 (H) x 480 (V) pixels |
| Focus Adjustment | Auto |
| Illumination | White LED |
| Lighting Method | Pulse lighting / DC lighting switchable |
| Built-in Ports | None (connects to IV-G10 amplifier via dedicated cable) |
| Protocols | None |
| Communication Expansion | Via amplifier |
| Supply Voltage | Supplied by connected amplifier |
| Power Consumption | Not available |
| Output Type | Not available (outputs via amplifier) |
| Operating Temperature | 0 to +50°C (no freezing) |
| Relative Humidity | 35 to 85% RH (no condensation) |
| Protection Rating | IP67 |
| Dimensions (H×W×D) | Not available |
| Weight | Approx. 75 g |
| Lifecycle | Discontinued; official Keyence product page marks model as discontinued with recommended replacement |
Key Technical Data
- Measurement Range: 20 to 500 mm installed distance
- Resolution: 752 x 480 pixels
- Temperature Range: 0 to +50°C
- Environmental Resistance: IP67, 35 to 85% RH
- Anti-interference: Not specified; amplifier handles signal processing
- Frequency Response: Not specified; depends on IV-G10 amplifier
- Sensitivity: Monochrome CMOS with white LED
- Linearity: Not specified; typical for vision sensor head
Installation Guide
Mount the IV-G500MA at a distance between 20 mm and 500 mm. Use the dedicated cable to connect it to the IV-G10 amplifier. The auto focus adjusts the lens automatically. Keep the front glass clean. Do not block the white LED. The IP67 housing resists dust and water. Avoid direct high-pressure spray. Confirm the field of view matches your target size. For 20 mm distance, the view is 10 x 7.5 mm. For 500 mm distance, the view is 200 x 150 mm.
Debugging and Maintenance Convenience
The auto focus cuts setup time. You do not need manual lens tuning. The amplifier handles all communication and output. This keeps the head small and light. The pulse lighting mode reduces motion blur. The DC lighting mode helps with static targets. Maintenance is simple. Check the cable connection. Clean the lens with a soft cloth. Replace the head if the image quality drops. The IP67 rating lowers downtime in dusty or wet areas.
Compatibility Notes
The IV-G500MA works only with the IV-G10 amplifier. It uses a dedicated cable. No other amplifier supports this head. The amplifier provides power and communication. The head has no built-in ports or protocols. All expansion happens through the amplifier. This model is discontinued. Check the Keyence recommended replacement before buying. Oiltech Controls can help you find a compatible alternative.
Certification Information
Not available from the source data. Please confirm with Keyence or Oiltech Controls before purchase. The IP67 rating shows resistance to dust and water. The 0 to +50°C range supports normal factory use. The 35 to 85% RH range fits most indoor environments.
Packaging List
- 1x Keyence IV-G500MA sensor head
- 1x Dedicated cable for IV-G10 amplifier (if included by seller)
- 1x Quick guide or datasheet (if provided)
Please confirm the exact contents with Oiltech Controls before order.
Warranty and Shipping
All products from Oiltech Controls include a 12-month warranty. We ship by FedEx, UPS, and DHL. Each item is tested before shipment. We offer technical verification before dispatch. Contact us for stock and lead time. This model is discontinued. We support obsolete control systems.
Why Buy From Oiltech Controls?
- 15+ years in industrial automation spare parts
- Global shipment support with FedEx, UPS, DHL
- Tested industrial surplus and refurbished options
- 12-month warranty on every order
- Technical verification before shipment
- Support for obsolete control systems
We help you keep old lines running. Our team checks every part. We pack safely for long transport. You get clear tracking and fast replies.
Typical Applications and Diagnostic Capabilities
Use the IV-G500MA for presence checks, position checks, and basic vision inspection. It fits small part detection. It also works for label alignment and assembly verification. The monochrome CMOS gives good contrast for shape checks. The auto focus helps when the target distance changes. The white LED supports stable lighting. The IP67 body suits dusty or wet cells. The amplifier handles image processing and diagnostics. This head does not run diagnostics alone. Pair it with the IV-G10 for full function.
FAQ
Q: Is the IV-G500MA still available?
A: It is discontinued. Keyence recommends a replacement. Oiltech Controls can offer tested surplus or refurbished options.
Q: What amplifier does it need?
A: It works only with the IV-G10 amplifier.
Q: Does it have built-in ports?
A: No. It connects to the amplifier with a dedicated cable. All ports and protocols are on the amplifier.
Q: What is the warranty?
A: 12 months from Oiltech Controls.
Q: How do you ship?
A: We use FedEx, UPS, and DHL. Contact us for rates and delivery time.
Q: Can you test before shipping?
A: Yes. We perform technical verification before shipment.
