Product Overview
- The E82ZAFCC201 is a high-performance CANopen Function Module.
- It belongs to the reliable Lenze 8200-series inverter range.
- This PLM Function Module enables seamless system bus communication.
- The product is currently in the Phase-Out stage for legacy support.
- Engineers use it for precise control and real-time data exchange.
Technical Specifications
- Brand: Lenze
- Model: E82ZAFCC201
- Frequency Response: Single-track 0 to 10 kHz or dual-track 1 kHz.
- Logic Levels: Low 0 to 3 V and High 12 to 30 V HTL levels.
- Input Resistance: High-precision 3.3 kOhm for stable signal processing.
- Signal Propagation: Ultra-fast response time of 5 ns/m.
- Cable Support: Shielded twisted pair with 120 Ohm impedance.
- Measurement Range: Distance up to 1000 meters with AWG20 cable.
- Power Supply: Integrated 20 V output with 0.6 W maximum load.
- Dimensions: Compact 6.30 x 7.60 x 2.50 cm for easy fitting.
- Weight: Lightweight 0.10kg construction for vibration resistance.
- Export Control: ECCN N for simplified global logistics.
Installation and Compatibility
- Plugs directly into the Lenze 8200 series drive communication slot.
- Compatible with all standard CANopen industrial network environments.
- Simple terminal wiring via X3.2 and X3.3 connection points.
- Supports CINH (Controller Inhibit) for safe drive blocking operations.
- Requires minimal configuration via parameter C0425 for frequency inputs.
Diagnostics and Maintenance
- Monitor terminal status directly through the inverter keypad or software.
- Easy troubleshooting via defined HTL logic level thresholds.
- Verify cable integrity using the specified 120 Ohm impedance matching.
- Modular design allows for rapid replacement to minimize machine downtime.
Typical Application Scenarios
- Synchronized multi-axis motion control in packaging lines.
- Long-distance communication for centralized factory automation systems.
- High-speed pulse counting for precise motor speed regulation.
- Industrial fan and pump control via system bus integration.
Shipping and Warranty
- Warranty: 12-month quality guarantee on all units.
- Express Delivery: Global shipping via FedEx, UPS, and DHL.
- Package List: One Lenze E82ZAFCC201 module in protective packaging.
Frequently Asked Questions (FAQ)
- Is this module still available? Yes, we stock Phase-Out units for maintenance needs.
- What cable should I use? Use a 120 Ohm shielded twisted pair for 300m+ distances.
- Can I return it? We offer a 12-month warranty for any manufacturing defects.
Contact Information
- For technical support, email: info@oiltechcontrols.com
- WhatsApp our engineering team: +86 158 8020 0923
- Please download the official datasheet and manual from our resource center.
