Product Overview: TM5SDO8TA Digital Output Module
The TM5SDO8TA from Modicon TM5 series is a high‑density discrete output module with 8 transistor channels. It delivers 2A per output at 24V DC, making it ideal for demanding industrial logic control. This 1‑wire module fits seamlessly into Modicon M258 and LMC058 controllers, ensuring robust performance in automation systems.
Key Technical Specifications
| Brand | Schneider Electric |
| Model | TM5SDO8TA |
| Series | Modicon TM5 |
| Output Type | Transistor (Source logic) |
| Channels | 8 discrete outputs |
| Output Voltage | 24V DC (20.4…28.8V range) |
| Current per Channel | 2A (peak 12A) |
| Switching Frequency | ≤500 Hz (resistive load) |
| Response Time | ≤300 µs (both on→off and off→on) |
| Protection | Short‑circuit, overload, reverse polarity |
| Power Dissipation | ≤1.5 W |
| Isolation | 500 Vrms (channel‑to‑bus), no channel‑to‑channel |
| Operating Temp | 0…60°C (horizontal derating), 0…50°C (vertical) |
| Storage Temp | ‑25…70°C |
| Humidity | 5…95% RH (non‑condensing) |
| IP Rating | IP20 (IEC 61131‑2) |
| EMC Immunity | 8kV air / 4kV contact (ESD); 10V/m radiated |
| Vibration | 3.5mm (5…8.4Hz), 1gn (8.4…150Hz) |
| Shock | 15gn / 11ms |
Installation & Compatibility
- Mounting: DIN rail (horizontal or vertical). Use derating factors for >55°C.
- Wiring: 1‑wire connection; 24V DC supply (0mA I/O consumption).
- Compatibility: Fully works with Modicon M258, LMC058 motion controllers, and Modicon Quantum series.
- Diagnostics: 8 yellow LEDs (per channel) + red/green power LEDs for instant status check.
Ease of Use & Maintenance
- Self‑diagnostics: Short‑circuit and overload alerts reduce downtime.
- Fast response: ≤300 µs switching ensures precise control.
- Clear labelling: Colour‑coded LEDs simplify troubleshooting.
- No special tools: Standard screwdriver for wiring terminals.
Environmental & Certifications
- Standards: IEC 61131‑2, UL 508, CSA 22.2 No 142/213.
- Certifications: CSA, cULus, C‑Tick, GOST‑R, CE marked.
- Pollution degree: 2 (IEC 60664).
- Operating altitude: 0…2000m (storage up to 3000m).
Package Contents & Warranty
- Included: 1× TM5SDO8TA module, 1× product documentation.
- Warranty: 12‑month full coverage against manufacturing defects.
- Shipping: Fast delivery via FedEx, UPS, or DHL (tracking provided).
Typical Applications
- Discrete control in conveyor systems, packaging lines, and material handling.
- Actuator and solenoid valve driving in industrial machinery.
- PLC expansion for Modicon‑based automation islands.
- Replacement/upgrade in legacy Modicon Quantum setups.
Diagnostic Capabilities
- Real‑time monitoring: Per‑channel LED status (yellow = ON).
- Fault detection: Automatic short‑circuit and overload shutdown.
- Leakage current: Only 5µA when switched off – safe for sensitive loads.
- Power indication: Red (fault) / Green (OK) LEDs for supply health.
Frequently Asked Questions
- Q: Can it drive inductive loads? A: Yes, with external freewheeling diode (not internal).
- Q: What is the max total current? A: 8A per common (sum of all channels).
- Q: Is it compatible with 5V logic? A: No, it uses 24V DC only.
- Q: Does it support hot‑swapping? A: No, power off before installation.
Why Buy From Oiltech Controls?
- 15+ years in industrial automation spares – deep domain expertise.
- Global logistics – we ship to over 60 countries with FedEx/UPS/DHL.
- All items are tested (surplus/refurbished) for guaranteed performance.
- 12‑month warranty and technical verification before shipment.
- We support obsolete control systems – including Modicon Quantum.
