MTL3052 Digital Signal Isolator – High-Speed Hazardous Area Protection
Secure Digital Communication in Explosive Areas
The MTL3052 provides high-frequency isolation for digital signals in hazardous locations. Ideal for MTL800 multiplexer systems with dual output options for flexible integration.
Key Features
- 10kHz bandwidth for digital signals
- Dual output options (100Ω/180Ω)
- Compact 130g design
- Low 160mW power consumption
- Replaceable 50mA fuse protection
Technical Specifications
| Model: | MTL3052 (Full: MTL3052-RU-18-0-0) |
| Input Voltage: | 4-12V DC |
| Output Options: | 15V @ 100Ω or 180Ω |
| Bandwidth: | DC to 10kHz |
| Safety Ratings: | 15V, 83.3mA-150mA |
| Isolation: | 250V AC/DC |
| Temp Range: | -20°C to +60°C |
Flexible Installation
- Terminals 5-6: 100Ω output
- Terminals 6-7: 180Ω output
- 4-12V DC power input
- Replaceable fuse protection
Safety Certifications
Approved for Zone 0 IIC T4-T6 and Division 1 Group A/C. FM certified with 15V output.
What’s Included
- 1 MTL3052 isolator unit
- Spare 50mA fuse
- Quick start guide
Expert Questions
- When to use 100Ω vs 180Ω output?
100Ω for systems with surge protectors/higher resistance. - Can it handle analog signals?
Optimized for digital (up to 10kHz bandwidth). - Maximum cable length?
50m for optimal digital signal integrity. - Replacement fuse specification?
50mA, 5x20mm glass time-lag. - Can I use for encoder signals?
Yes – with proper current limiting resistors.
Shipping & Warranty
Fast global delivery via FedEx/UPS/DHL. Your MTL3052 includes 12-month performance guarantee.
