MTL4045C – Safe Zone to Hazardous Area Signal Isolator
Reliable 4-20mA Signal Transfer for I/P Converters
The MTL4045C safely transfers control signals to devices in explosive areas. Designed for I/P converters with open-circuit detection and up to 800Ω load capacity.
Key Specifications
| Signal Range | 1.0-21.4mA (extended range) |
| Output Power | 16V @20mA (800Ω max) |
| Accuracy | ±20µA @20°C |
| Response Time | 100ms settling time |
| Power Consumption | 1.0W @24V (50mA) |
Installation FAQs
- What’s the difference from MTL4045B?
MTL4045C detects open circuits only (no short circuit detection). - Maximum cable length supported?
Works reliably up to 200m with proper shielding. - Can I use it with positioners?
Yes, compatible with most I/P converters and positioners. - Is calibration required?
No, factory calibrated for immediate use. - Power supply requirements?
20-35V DC (40-55mA current draw).
Ordering & Support
Available for fast shipping via FedEx, UPS, DHL. Backed by 12-month quality guarantee.
