MTL5022 Hazardous Area Controller – Safe Zone to Zone 0 Power Interface

Reliable Hazardous Area Control

The MTL5022 safely connects safe-area switches to Zone 0/Div.1 hazardous area devices. Drives intrinsically safe loads up to 60mA with flexible power options.

Key Technical Data

• Brand: MTL | Model: 5022 (Full code: MTL5022-EX-DRV)
• Output Voltage: 12.9-24V DC
• Current Limit: 60mA protected
• Input Voltage: 20-35V DC
• Load Types: IS devices, LEDs, simple apparatus
• Power Consumption: 115mA @24V (typical)
• Status Indicator: Yellow LED
• Certification: ATEX Zone 0, IIB

Connection Guide

• Output: Terminal 1(-) and 2(+)
• Power: Terminal 11(-) and 12(+)
• Earth leakage detection: Terminal 3

5 Common Questions

1. Can MTL5022 power small motors?
   Yes, if certified IS and under 60mA.
2. What does yellow LED indicate?
   Normal operation status.
3. Is reverse polarity protected?
   Yes, internal protection circuits.
4. Can I connect multiple loads?
   Yes, if total current ≤60mA.
5. What cable size is recommended?
   0.5-1.5mm² for most installations.

Package Details

• 1x MTL5022 controller unit
• Installation sheet
• DIN-rail mounting hardware
• 12-month quality guarantee
• Fast shipping via FedEx/UPS/DHL
